As China famous pluggable terminal block supplier, Sun has our research and development team to bring out various kinds of products and solutions to meet the customers' requirements. Our products are widely applied to electronic equipment, machine building, plant engineering, process industry. We provide high-quality and low price pluggable terminal block, pluggable terminal strip, and pluggable terminal block connector.
Sun's terminal blocks also provide a crucial role for good wire management in your project. Configurations are offered for power distribution, DIN rail styles, standard terminal blocks, and wire-to-board. There is also a wide variety of specialized styles.
Mode | EX2EDGKDM-5.0/5.08 |
Material | |
Pitch | 5.0/5.08 mm |
Poles | 2~22P |
Screws | - |
Contact | Phosphor bronze Ni plated |
Wire cage/Wire guard | Stainless steel |
Housing | PA66, UL94V-0 |
Electrical | |
Rated voltage | 300V |
Rated current | 10A |
Withstanding voltage | AC1500V/1 Min |
Wire range | 26-12AWG |
Mechanical | |
Temp range | -40℃~+105℃ |
Max soldering | +250℃ 5 Sec |
Torque | - |
Strip length | 7~8mm |
Sun is top 10 terminal block manufacturers in China, providing high-quality and low price pluggable terminal block, pluggable terminal strip, and pluggable terminal block connector.
